MINIMUM SPACE
MAXIMUM STORAGE

ÜÇGE DRS provides innovative warehouse solutions to global and
national brands across logistics, retail and all industrial branches.
Specialized on heavy and light duty warehouse racking systems and smartly
designed warehouse projects and storage solutions.

Pallet Automatic Storage Racking Systems

MultiPal AS/RS Automated Storage Systems

MOBIPAL WAREHOUSE RACKING SYSTEM MOBILE RACK PALLET RACK

Shuttle Racking Warehouse Storage Systems

FASTER, STRONGER, HIGHER

Groundbreaking developments in the world of technology, such as artificial intelligence and smart intralogistics and automation, will further customize customer experience in many areas in retail and logistics within the near future and quality of service will continuosly expand.

ÜÇGE, with the power of R&D center and over 100 engineers; provides wide scope projects, designs new solutions and constantly adds new patented products to implement the smart storage technologies for the future.

ÜÇGE DRS

WAREHOUSE RACKING SYSTEMS

Years Experience

2000+

Completed Project

Export to Countries

100.000

Production Area

AR-GE

The industry’s first
R&D Center

Prize

AS/RS Pallet

AS/RS Pallet automation is the combination of hardware
and control systems including delicate, accurate and
quick retrieval, storage and transfer of the pallets

AS/RS TRAY

Goods in all shapes through special carrying trays; It is a combination of hardware and software that stacks
precisely, accurately and quickly with the best use of volume and brings it to the person when needed
AS/RS BOX

It is the combination of hardware and control systems including delicate, accurate and quick retrieval, storage
and transfer of some products composed of various parts placed in boxes, packages or parcels

AS/RS MULTİPAL

It is a kind of full automation system which is let youstore products in minimum area. This system provides
fast and safe pallet flow in all three direction with high automation
AUTOMATED (MOBILE) RACKING SYSTEM

t’s a kind of back to back storage system whichcan move on the direction of the aisle as block, and which is founded on mobile chassis hence increasing the capacity of the warehouse without
losing direct access to each pallet.

AUTOMATIC LEVEL DRIVE-IN/ DRIVE-TROUGH

Known as Drive-in Automation, it is a more developed and much more efficient automatic storage system thanks to its speed. Maximum storage in minimum are is provided by loading products at the depth of the platforms.
BACK TO BACK STORAGE SYSTEMS

It’s an easily applicable and economical warehouse racking system which can be used to stack pallet and packaged
products of any size, and which enables to access every product directly and independently. .

HR NARROW AISLE SYSTEMS

It’s a system targeting maximum storage in minimum area with the use of narrow aisle forklifts in high warehouses as
a high rack system
DRIVE-IN (FILO)

It’s a stacking system in which products of the same size and content are placed in the canals one after another. It’s preferred in warehouses in which product circulation is low and product range is low. Increases productivity by
using approximately 85% of the storage space.

SILO RACKING SYSTEMS

Also known as “the clad system”, the silo racking warehouses can be created with every kind of warehouse racking system. It’s a more efficient and economical warehouse option especially if you have a high warehouse.
MEZZANIN PLATFORM RACKING
SYSTEMS

These are the walk ways or platforms on which manual loading/unloading is performed in order to make best
use of height and increase the working space at high warehouses.

CANTILEVER RACKING SYSTEMS

It’s the warehouse racking system which is created with brackets installed over carrier uprights for the storage of long and bulky products such as pipes, profiles and plates.
DOUBLE DEEP RACKING SYSTEMS

In this system, which is a different practice of back-to-back storing systems, loading at a depth of successive 2 pallets is possible. Hence fewer aisles are used, and storage
capacity is increased. As the system is double-depth, the pallet positioned in the rear section can be accessed with
the telescopic carrier of the crane fork

PALET LIVE STORAGE SYSTEMS

In this racking system pallet products of the same size and content are loaded in the canals in which roller cassettes
having a light slope are placed. These products flow from the loading point to the unloading point under the effect
of gravity in a controlled manner.
BOX LIVE STORAGE SYSTEMS

In this system such products as packets and packages are slid over mini rollers placed with a light slope. Products
are loaded at one point, and unloaded from the reverse point. And it operates with gravity and zero energy

PUSH BACK ROLLER RACKING
SYSTEM

It’s a storage system ideal for saving space in warehouses consisting of two or more pallets and having a medium
cycle. Since there is a single direction loading/unloading, first in last out (filo), and after the first pallet is loaded the
new pallet is loaded by being pushed backward over the rolls
GARMENT RAIL STORAGE SYSTEMS

It’s a system which is designed for the storage of the goods which can be hanged. They can be used by being
adjusted to the ‘Mezzanine System’ warehouses known as layered systems

DO IT YOURSELF STORES

The most important chains in the World retail business prefer ÜÇGE solutions. Hundreds of designs and alternatives which are developed for each product and which increases the sale of that product by featuring it, are remarkable.
M60 STORAGE SYSTEMS

It’s an esthetical and practical racking system which can be used in all storage types thanks to its modular structure.
It’s primarily preferred to be used in the warehouses where heavy and middle duty loads are stacked manually, and in
archive warehouses.
